CIGWELD WELDSKILL 140 ARC WELDER

The WeldSkill 140 is a single phase welding inverter with a user-friendly control panel, a practical push-button operation for mode selection, clearly visible LED indicators and sturdy large control knob.

Affordable, compact and light-weight, this unit is a great addition to the shed ensuring the ultimate portability for the Home Handyman, Tradesman, Farmer or Maintenance Worker.

In addition to its appealing design and functional features, the WeldSkill 140 provides the added reassurance of a high-quality welding inverter that complies with Australian Standards.

Simply plug it in at home or into any standard 10 Amp power point and get welding right away!

• Twist lock electrode holder
• Rugged case with carrying handle and carry strap
• 4m long electrode holder and work leads
• Push button weld mode selector with LED indicators
• 3 Year Warranty

Dimensions

H200mm x W120mm x D315mm

Weight
4.7kg

Cooling
Fan Cooled

Processes
Lift TIG (GTAW), Stick (MMAW)

Australian Standards
AS 60974.1-2006 / IEC 60974-1

Supply Voltage

240V AC ± 10%

Current Range

10 - 140A

Maximum Input Current

26.3 Amps

Generator Requirement
6.0 kW (7.5 kVA @ 0.8 PF)

Duty Cycle
Stick (MMAW): 140 Amps @ 15% Duty Cycle (40C, 10 mins)
TIG (GTAW): 140 Amps @ 35% Duty Cycle (40C, 10 mins)

Supply Plug Lead

10 Amps
