WIN TIG DC 220 M

SKU 553

Product Details

Brand: CEBORA

Features

User-friendly LCD Display
EVO LIFT function allows to place the electrode in the exact position avoiding the piece oxidation and the heat control
EVO START function in order to optimize edge junction
APC TIG (Active Power Control) welding process which guarantees a deeper penetration, a more stable arch, avoids the electrodes to get stuck to the piece, allows to adapt the arc to the welding conditions only with the torch movement
Intermittence Pause Time Welding function which makes welding clearer with a time regulation in a second cents range
Pulse function selectable up to 2,5 kHz
eXtra Pulse (XP) function: a very high frequence pulse that works on small thicknesses where the transferred heat must be minimal
Possibility to match a low pulse frequence to the XP process in order to improve the penetration and the welding speed on small-medium thicknesses
JOB function which makes it possible to save up to 9 welding programs
Wiz function helping the operator to take quick decisions based on the desired welding process
The power source can also be powered by motor-driven generators of appropriate power (10 kVA)

TECHNICAL SPECIFICATIONS

553	Technical Specifications
TIG		MMA
115 V 50/60 Hz +15% / -20%	230 V 50/60 Hz +15% / -20%	115 V 50/60 Hz +15% / -20%	230 V 50/60 Hz +15% / -20%	Alimentazione monofase Single phase input
25 A	16 A	25 A	16 A	Fusibile ritardato Fuse rating (slow blow)
3,8 kVA 40% 3,1 kVA 60% 2,2 kVA 100%	5,3 kVA 30% 3,2 kVA 60% 2,7 kVA 100%	3,6 kVA 35% 2,8 kVA 60% 2,3 kVA 100%	4,5 kVA 35% 3,8 kVA 60% 3,4 kVA 100%	Potenza assorbita Input power
5 ÷ 160 A	5 ÷ 220 A	10 ÷ 110 A	10 ÷ 140 A	Campo di regolazione della corrente Current adjustment range
160 A 40% 140 A 60% 110 A 100%	220 A 30% 160 A 60% 140 A 100%	110 A 35% 90 A 60% 75 A 100%	140 A 35% 125 A 60% 115 A 100%	Fattore di servizio (10 min. 40° C) Secondo norme IEC 60974-1 Duty Cycle (10 min.40°C) According to IEC 60974-1
IP23S	Grado di protezione Protection class
16 kg	Peso Weight
207x500x411 mm	Dimensioni (LxPxH) Dimensions (WxLxH)
