KEMPPI FASTMIG X PULSE MIG, WFX FEEDER WELDING PACKAGE

INTELLIGENT, FLEXIBLE, UPGRADABLE WELDING SOLUTION.

Kemppi's FastMig X product series offers highly specialized welding solutions and superior welding quality for demanding industrial applications. It features three alternative high-end configuration recommentations for three different purposes: FastMig X Regular for robust workshop use a MIG/MAG pulse welding, mainly for welding thick plates, FastMig X Pipe for pipe and root welding and FastMig X Intelligent for demanding welding applications, for all metals and processes, including welding of thin sheets.

All configurations are equipped with either the FastMig X 350 or the FastMig X 450 power source, which is a multi-process CC/CV power source that is ideal for synergic and pulsed MIG/MAG welding, MMA welding, and TIG welding. Used in configuration with WFX wire feeders, they form a welding system that easily meets every welding need and the quality management requirements of any metal fabrication workshop.

Contact us for a package to suit your needs.

BENEFITS

• Multi-process power solution: MIG, 1-MIG, pulsed MIG, MMA, and TIG
• Arc Mobile Control brings flexible way to use and control the welding machine
• WiseRoot+ option for optimized root welding
• WiseThin + option for optimized sheet and position welding: Mixed gas quality with lower cost CO2 shielding gas
• Precise arc voltage function measures and shows the actual arc voltage on the display
• Save time by combining two wire feeders on the same power source for alternative filler wires
• SuperSnake sub-feeder connectivity for maximum reach

]

FASTER WELDING

Boost your efficiency by utilizing up to 30 % faster travel speeds with WiseFusion

LOWER HEAT INPUT

Reduce distortion and time consuming straightening work and improve the impact toughness of high strength steels with WiseFusion

BEST REACH ON THE MARKET

Distance and access will no longer be a problem with the SuperSnake subfeeder accessory

Software

WiseFusion

OPTIMIZED WELDING FUNCTION FOR QUALITY, SPEED AND EASE OF USE

WiseFusion optimized welding function produces a very narrow and energy dense welding arc making welding faster and heat input lower. Focused penetration area allows the welding of narrow and deep grooves. WiseFusion results in excellent penetration without a risk of undercut. Narrower arc also facilitates weld pool control in position welding. WiseFusion ensures optimum arc length eliminating the need for constant parameter settings. Adaptive and automatic arc length regulation maintains the arc always within the short circuit boundaries and raises your arc-on time.

WisePenetration

WELD WITH INVARIABLE PENETRATION EVEN IN DEMANDING CONDITIONS

WisePenetration optimized welding function is designed to keep welding current and thus penetration invariable regardless of the changes in stick-out length in manual welding.

Normally in MIG/MAG welding the power to the weld pool is changing as the welder or weld piece dictates the distance between the joint and welding gun nozzle. These deviations may result in quality issues such as lack of fusion, incomplete or inconsistent penetration, changes in weld profile and of course welding spatter.

WisePenetration solves these issues and reduces the need for post-grinding and repair work. The function prevents the current from dropping down by actively adjusting wire feeding. This helps to keep the weld mechanical properties on a desired level and prevents welding defects. The user sets the wished current level, and with the help of WisePenetration, the current level does not drop below this level when stick-out length increases.

WiseThin+

INCREASE WELDING SPEED AND ACHIEVE BETTER QUALITY

WiseThin is a tailored cold arc process for manual and automated thin sheet welding and brazing. Typical applications include automotive manufacturing and quality light plate fabrication in ferrous and stainless steel materials.

The WiseThin+ process is based on precise voltage measurement and current control. Mixed gas welding characteristics with pure CO₂. Expands the parameter window and thus reduces the need to use smaller wire diameters. Soft and pleasant arc characteristics. Excellent welding characteristics for welding plate thicknesses 0.8…3.0 mm. Reduces heat input and thus also deformation. Excellent arc ignition for tack and intermittent welds.
