ALLCLEAR TA100 GRINDING/WELDING TABLE FUME FILTER UNIT

ALLCLEAR TA100 GRINDING/WELDING TABLE FUME FILTER UNIT

The Allclear TA100 is a mobile down draft table suitable for welding and light grinding applications. Equipped with a cassette-type main filter and a G4 + mesh prefilter, the TA100 is an ergonomic and compact system that provides ultimate ease of use.

It provides 7m per second airspeed on the working surface provided by a 1kW AC motor 240V. The TA100 is made from a rust-proof galvanized body and is mounted on caster wheels for greater mobility. The unit offers a fume extraction solution for extracting dangerous welding and grinding fume particles ensuring a safe and healthy working environment.

Filters:

F9 Box Filter: 91990117
Spark Arrestor: 91990119

Technical Data:

Motor Power: 1.0 kW
Mains Supply: 220v / 50Hz
Maximum Air Flow: 3000m3 per hour
Average Flow at Surface: 1200m3 per hour
Main Filter: F9 cassette filter
Pre Filter: G4 + mesh
Carrying Capacity: 500 Kg
Body: Galvanised Steel
Fan: Aluminium
Noise: 68 dba
Sound Insulation: Acoustic Sponge
Dimensions mm (L x W x H): 700 x 1100 x 1255
